| Introduction: |
| It is a Pre-Programmed Logic Controller. It is based on the single chip micro-processor logic. It has custom built dedicated programs as per logic sequence given by user with panel flush mounting facility. It is useful for Pumps Industry, HVAC & R Industry, Engineering & Food Processing Industry,Power Industry. It senses Digital Relay Inputs. It offers Logic Controllers for smallest needs like 4 I/O, 8 I/O, 16 I/O & 32 I/O etc. It can be best developed as OEM Component. It is totally custom built, for the specific application of machinery or plant. | |
|
|
| Features: |
· Powerful Microprocessor Circuit.
· Suitable for digital or relay Input & Outputs.
· Customized Hardware with open PCB or with enclosures.
· Built-in System Watchdog LED.
· Customized Hardware with open PCB or with enclosures.
· Built-in System Watchdog LED.
· Customized LED Indications.
· AC/ DC Auxiliary Supply.
· RS 232 or RS 485 output (Optional)
· Key Board & digital display (Optional)
| |
|
| |
|
|
| Application Areas: |
| It is useful for Pumps Industry, HVAC & R Industry, Engineering & Food Processing Industry,Power Industry. It senses Digital Relay Inputs. It offers Logic Controllers for smallest needs like 4 I/O, 8 I/O, 16 I/O & 32 I/O etc. It can be best developed as OEM Component. It is totally custom built, for the specific application of machinery or plant. | |
|
|
| Technical Specifications: |
|
|
|
|
|
Specifications |
| 1 |
Auxillary supply |
240 V AC +10%,-15% |
| 2 |
Input signal |
Potential free contacts |
| 3 |
Output signal |
8/16 outputs (Relay or open collector) |
| 4 |
Output contact rating |
240 V AC 5 Amps. (resistive) for Relay output 60mA sink capacity at 12 DC for open collector output |
| 5 |
Operating temperature |
0-60° C |
| 6 |
Dimensions |
Overall (L x W x D) 144 x 144 x 215mm (8 input / output) 216 x 144 x 215 mm (16 input / output) |
| 7 |
Mounting (L x W) |
138 x 138mm (8 input / output) 210 x 138 mm (16 input / output) | | |
|
|
|
|
|
|
