Specifications |
1 |
Supply Voltage |
System 110 / 240 / 380 / 415 V AC ±20%; Auxiliary 110 / 240 / 380 /415V AC ±20% |
2 |
Ext. Input |
1A or 5A (Selectable) CBCT |
3 |
Output contact |
1 CO / 2 CO (Pick up on Fault) |
4 |
Trip setting |
Under Current N.A.; Over Current 10% -100% (adjustable) of CT sec; Under Frequency —; Over Frequency —; Under Power —; Over Power —; Cos-Ø —; Reverse Power — |
5 |
Input Current Range |
— |
6 |
Power On Delay |
N.A. |
7 |
Trip Time Delay |
1-10 (adjustable) ±10% OR Instant <1sec |
8 |
Resetting |
Manual / Remote (Selectable) |
9 |
Weight |
550gms. |
10 |
Dimensions (mm) |
Overall (L x W x D) 76 x 56.5 x 11.7; Mounting (L x W) 67 x 46 |
